Digital overcurrent relay with 3×3 digit LED display TRM-100

Description

Digital thermal relays are designed to protect and control loads from damage due to high current.

Adjustable overload value: 40A – 100A 50% fixed current asymmetry Adjustable error delay time Adjustable operating mode (Automatic, Semi-automatic, Manual) Package includes current transformers Technical specifications: 3×3-digit display + 5 LEDs High current (overload): TRM-50: 15A – 50A TRM-100: 40A – 100A TRM-200: 90A – 200A TRM-300: 190A – 300A TRM-400: 290A – 400A Delay (t):
TRM-50/100: 0.1 s – 20 s TRM-200/300/400: 1 s – 200 s Connection Type: Terminal Contact: 5A/250VAC (resistive load) Cable Diameter: 2.5 mm² Weight: max. 250 g Mounting.
