ONKA 25mm2 Screw rail connector terminal block DIN rail terminal 2-wire blue, 1010065

Description

Threaded busbar rail connector / DIN rail terminal 2-wire blue, ONKA, made in Turkey

The ONKA coupler / terminal block is a reliable solution for anyone looking for functional and durable elements in electrical installations.
Made of high quality materials, the connector guarantees long term use and resistance to mechanical damage.

Technical parameters

Cross section of the connected single wire up to: 25mm2
Colour: blue
Insulating material of the main housing: polyamide (PA6.6)
Contact/bridge material: CK45 Steel/Copper
Torque: 2.0 Nm
Connection position: lateral / side
Cable strip length: 18mm
Electrical connection type: screw clamp
Rated voltage: 750V
Rated current: 101A
Operating temperature range from: -40°C
Operating temperature range up to: 140°C
Mounting method: DIN 35 mm mounting rail
Norm: EN-60947-7-1
